83-85, 70178 Stuttgart, Germany including all of its affiliates within the meaning of Section 15 et seq. I consent to the use of my email address to send editorial newsletters by Mesago Messe Frankfurt GmbH, Rotebühlstr. Consent to the use of data for advertising purposes More detailed information is available in our privacy policy. Where we collect personal data from you, we process the data in compliance with the relevant data protection regulations. It goes without saying that we treat your personal data responsibly. There is not a straightforward and definitive answer to this question. Unfortunately, we cannot say which is “better” because the matter is highly subjective. Power electronics market 2020: Winners, losers and opportunities Which is better?īoth MOSFET and BJT have unique characteristics and their own pros and cons. A MOSFET’s structure is inherently more complex than a BJT’s structure.A BJT depends on the current at its base terminal whereas a MOSFET depends on the voltage at the oxide-insulated gate electrode.MOSFETs are ideal for high-power applications whereas BJTs are more commonly used in low-current applications.The MOSFET has a source, drain, and gate whereas the BJT has a base, emitter, and collector. While both have three terminals, these differ.The MOSFET (voltage controlled) is a metal-oxide semiconductor whereas the BJT (current controlled) is a bipolar junction transistor.There are many differences between the MOSFET and BJT. In either case, the current’s direction in the base is the same as the collector. In the NPN, the polarity is the opposite and current flows in the emitter and out the collector. Current flows in the collector of a PNP and out of the emitter. In between these structures is a small layer of the other doping agent called the “base”. Each type has a large collector element and a large emitter element which are doped in the same way. There are two types of BJT – PNP and NPN. A BJT has three pins – the base, collector, and emitter – and two junctions: a p-junction and n-junction. The Bipolar Junction Transistor (BJT) is a current-driven device (in contrast, MOSFET is voltage-driven) that is widely used as an amplifier, oscillator, or switch, amongst other things. Understanding the difference between n- and p-type semiconductors What is BJT? Because gate terminal voltage is positive or negative, channel conductivity is decreased.Įnhancement mode: when the gate terminal’s voltage is low, the device does not conduct unless more voltage is applied to the gate terminal. This often sees MOSFETs being used in low-power devices or as building blocks to reduce power consumption.ĭepletion mode: When the gate terminal’s voltage is low, the channel exhibits maximum conductance. This level of insulation roots low power consumption and is the primary benefit of this type of transistor. The gate terminal itself is made from metal and is detached from the source and drain terminals using a metal oxide. Likewise, in n-channel MOSFETs, the source and drain terminals are made of n-type semiconductor. In p-channel MOSFETs, the source and drain terminals are made of p-type semiconductor. This means that in total, there are four different types of MOSFET. Both of these types can either be in enhancement or depletion mode (see figure 1). MOSFETs are available in two types, “ p-channel” and “ n-channel”. The voltage that is applied across the gate controls how much current flows into the drain. In a MOSFET, the drain is controlled by the voltage of the gate terminal, thus a MOSFET is a voltage-controlled device. Metal-Oxide- Semiconductor Field-Effect Transistor (MOSFET) is a kind of Field Effect Transistor (FET) that consists of three terminals – gate, source, and drain.
